Hi Speed Aluminium Foil Slitting Machine
Introduction:
Hi Speed Aluminium Foil Slitting Machine is very suitable for slitting cellophane, BOPP, PET, CPP, CPE, PVC, aluminum foil, paper, etc.
feature
1. The control system of the machine is integrated with the machine body to ensure a high level of automation and flexible operation.
2. The material support of Hi Speed Aluminium Foil Slitting Machine adopts LPC automatic deviation control system.
3. The slitting machine is usually equipped with round knives, and flat knives are also optional. The user can choose which one to use according to the material.
4. The winding roller adopts a constant pressure roller, which makes the winding more stable.
5. The winding device adopts cantilever structure. The unloading tower can be installed according to user requirements.
6. The unwinding device of the slitting machine also has a doffing type automatic loading function.
Welcome to contact us for more details!
Specification:
Unwinding diameter | Max Ø1000mm |
Rewind diameter | Max Ø600 mm |
Max working width | 1000mm |
Unwind core diameter | Ø76 mm (3") / Ø152 mm(6") |
Rewind core diameter | Ø76 mm (3") |
Mechanical speed | Max 250 m/min (depending on working conditions) |
Slitting types | Razor blade /Circular knives(Optional)slitting system |
Applicable materials | Al compound packing film and Alumium Foil |
Material thickness range | 0.012mm-0.15mm |
Traction motor | 1 Set 5.5kw |
Rewinding motors | 2 Set 5.5 kw |
Unwinding motor | 1 Set 7.5kw |
Total energy consumption | ≈20kw |
Pneumatic pressure | 0.6 Mpa |
Power supply voltage | AC 380V±5% Three-phase five-wire、50Hz |
Un. tension control | Constant tension |
Re. tension control | Taper tension |
Coiling method | Center winding( Double rewinding shafts) |
Loading method | Shaft-less cone head |
Unloading method | Side arm, auxiliary discharging rack |
Guiding accuracy | ±0.2mm |
Web guiding Movement range | ±50mm |
Machine dimension | L2000*W3000*H1870 |
Weight | 4500kg |
Color | standard KESHENG colors (reference picture) |
