High Speed Plastic Film Slitter Machine
1. Engineers can go abroad
2. One year warranty
3. Static Eliminators (optional) - Static Eliminator can be installed on machine as per customer’s option.
4. Offloading Unit - The machine has its own unloading rack. After slitting, the finished roll can be unloaded to the unloading rack. After rotating the arms, it is convenient to unload the material so as to reduce working intensity, labor and loss.
2. One year warranty
3. Static Eliminators (optional) - Static Eliminator can be installed on machine as per customer’s option.
4. Offloading Unit - The machine has its own unloading rack. After slitting, the finished roll can be unloaded to the unloading rack. After rotating the arms, it is convenient to unload the material so as to reduce working intensity, labor and loss.
Send Inquiry
Product Introduction
Features:
1. Engineers can go abroad
2. One year warranty
3. Static Eliminators (optional) - Static Eliminator can be installed on machine as per customer’s option.
4. Offloading Unit - The machine has its own unloading rack. After slitting, the finished roll can be unloaded to the unloading rack. After rotating the arms, it is convenient to unload the material so as to reduce working intensity, labor and loss.
Application：
This is a hot-selling slitting machine for BOPP/CPP/PET/PE/soft aluminum composite film/aluminized film and other roll materials.
Parameter：
| Unwinding diameter | Max Ø800mm |
| Rewind diameter | Max Ø450mm |
| Max working width | 1300mm |
| Unwind core diameter | Ø76mm (3") / Ø152mm(6") |
| Rewind core diameter | Ø76mm (3") / Optional Ø152mm(6") |
| Min. slitting width | 30mm / Optional 25mm |
| Mechanical speed | Max 450m/min (depending on working conditions) |
| Material thickness range | 0.012mm-0.15mm |
| Traction servo motor | 1 Set 3.0 kw |
| Rewinding servo motors | 2 Set 3.0 kw |
| Blower motor | 1 Set 1.5 kw |
| Total energy consumption | Est. 12 kw |
| Pneumatic pressure | 0.6 Mpa |
Product Details：
